| Facial Recognition |
| Face Image Library | Up to 16 face image libraries;
HDD damage will not cause data loss in the face image library, because the library has been backed up by HDD and flash. |
| Face Image Comparison | 4 chs of face image comparison alarm (HD analog camera) |
| Motion Detection 2.0 |
| Human/Vehicle Analysis | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and reduce false alarms caused by objects like leaves and lights
Quick search by object or event type is supported |
| Perimeter Protection¹ |
| Human/Vehicle Analysis | Up to 8 chs (advanced model) |
| Facial Detection¹ |
| Facial detection and capture | Face image detection, face image search
4 chs face picture capture |
| Recording |
| Video compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding resolution | 8 MP/5 MP/3K/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Main stream:
8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
Sub-stream:
WD1/4CIF/CIF@25 fps (P)/30 fps (N)
|
| Video bitrate | 32 Kbps to 6 Mbps |
| Dual stream | Support |
| Stream type | Video, Video & Audio |
| Audio compression | G.711u |
| Audio bitrate | 64 Kbps |
| Video and Audio |
| IP video inputs | 16-ch (up to 32-ch), each up to 8MP |
| Analog video input | 16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| HDTVI input | 8 MP(3840 × 2160)@12/15 fps, 3K(2960 x 1665)@25/20 fps,3K(3328x1504)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps |
| AHD input | 5 MP (2560 × 1944) @ 20 fps, 4 MP (2560 × 1440) @ 25 / 30 fps,1080p @ 25 / 30 fps, 720p @ 25 / 30fps |
| HDCVI input | 8 MP(3840 × 2160)@12/15 fps, 3K(2880×1620)@25/20fps, 5 MP(2592 × 1944)@20fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps |
| CVBS input | PAL/NTSC |
| CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω)
Resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI Output | 1 ch, 4K (3840 × 2160) / 30 Hz, 2K (2560 × 1440) / 60 Hz, 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz |
| VGA Output | 1 ch, 1920 × 1080 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz |
| Video Output Mode | HDMI / VGA simultaneous output |
| Audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ)
16-ch via coaxial cable |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
| Two-way audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Synchronous playback | 16-ch |
| Decoding |
| Decoding Capability | Up to 24 chs 1080p @ 30 fps |
| Network |
| Total Bandwidth | 256 Mbps |
| Network protocol | TCP/IP, PPPoE, DHCP, LTS Connect, DNS, DDNS, NTP, NFS, iSCSI, UPnP™, HTTPS, ON-VIF, ISUP |
| Network interface | 1,RJ45 10/100/1000 Mbps self-adaptive
Ethernet interface |
| Remote Connection | 128 |
| Wi-Fi | Connectable to Wi-Fi network by Wi-Fi dongle through USB interface |
| Auxiliary interface |
| SATA | 2 SATA interfaces, up to 12 TB capacity for each disk |
| Serial interface | RS-485 (half-duplex) |
| USB interface | Front panel: 1 × USB 2.0
Rear panel: 2 × USB 3.0 |
| Alarm in/out | N/A |
| General |
| Power supply | 12 VDC, 5 A |
| Consumption (without HDD) | ≤ 60 W |
| Working temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Working humidity | 10% to 90% |
| Dimension (W × D × H) | 384 × 317 × 52 mm (15.1 × 12.5 × 2.0 inch) |
