Camera
|
Sensor
|
1/3”
4Megapixel progressive CMOS
|
Effective Pixels
|
2688
(H) × 1520 (V)
|
ROM
|
128 MB
|
RAM
|
512 MB
|
Scanning System
|
Progressive
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100000 s
|
Min.
Illumination
|
0.0005
Lux@F1.6 (B/W, 30IRE) 0 Lux (Illuminator on)
|
IR
Distance
|
50 m
(164.0 ft)
|
IR
On/Off Control
|
Auto/Manual
|
IR
LEDs Number
|
1
|
Pan/Tilt/Rotation Range
|
Horizonal: 0°–360° Vertical:
0°–90° Rotation: 0°–360°
|
Lens
|
Lens
Type
|
Fixed
|
Mount
Type
|
M12
|
Focal
Length
|
2.8 mm
|
Max.
Aperture
|
F1.6
|
Field
of View
|
2.8
mm: Horizonal: 103.0°
Vertical: 55.0° Diagonal: 122.0°
|
Iris
Type
|
Fixed
aperture
|
Close
Focus Distance
|
2.8
mm: 0.9 m (3.0 ft)
|
DORI
Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
2.8 mm
|
56 m
(183.73 ft)
|
22.4 m
(73.49
ft)
|
11.2 m
(36.75
ft)
|
5.6 m
(18.37
ft)
|
Smart event
|
General IVS Analytics
|
Tripwire; intrusion (Recognition of human and vehicle)
|
Intelligent Search
|
Work together with Smart NVR to perform refine intelligent search,
event extraction and merging to event videos |
Video
|
Video
Compression
|
H.265;
H.264; H.264H; H.264B; MJPEG(only supported by sub stream)
|
Smart
Codec
|
Smart
H.265+/ Smart H.264+
|
Video
Frame Rate
|
Main stream (2688 × 1520@1–25/30 fps) sub stream (704 × 576@1–25
fps/704 × 480@1–30 fps) third stream (1280 × 720@1–25/30 fps) |
Stream
Capability
|
3
stream
|
Resolution
|
4M
(2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 ×
960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480);
CIF (352 × 288/352 × 240)
|
Bit
Rate Control
|
CBR/VBR
|
Video
Bit Rate
|
H.264:
32 Kbps–8192 Kbps H.265: 12
Kbps–8192Kbps
|
Day/Night
|
Auto(ICR)/Color/B/W
|
BLC
|
Yes
|
HLC
|
Yes
|
WDR
|
120 dB
|
White
Balance
|
Auto/natural/street lamp/outdoor/manual/regional custom
|
Gain
Control
|
Auto/Manual
|
Noise
Reduction
|
3D DNR
|
Motion
Detection
|
OFF/ON
(4 areas, rectangular)
|
Region
of Interest(RoI)
|
Yes (4
areas)
|
Smart
IR
|
Yes
|
Rotation
|
0°/90°/180°/270° (Supports 90°/270° with 1080p resolution.)
|
Mirror
|
Yes
|
Privacy Masking
|
4
areas
|
Audio |
Built-in MIC
|
Yes
|
Audio Compression
|
G.711a; G.711Mu; G726
|
Alarm |
Alarm Event
|
No SD
card; SD card full; SD card error; less service time of SD card
(smart card supports); network disconnection; IP conflict; illegal
access; voltage detection; security exception; motion detection;
video tampering; scene changing; input abnormal; intensity change;
tripwire; intrusion; SMD
|
Network
|
Network
|
RJ-45
(10/100 Base-T)
|
Protocol
|
IPv4;
IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP;
SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS;
PPPoE; 802.1x; Bonjour
|
Interoperability
|
(Profile S/Profile G);CGI;P2P;Milestone;Genetec
|
Cyber Security
|
Video encryption; firmware encryption; configuration encryption;
Digest; WSSE; account lockout; security logs; IP/MAC filtering;
generation and importing of X.509 certification; syslog; HTTPS;
802.1x; trusted boot; trusted execution; trusted upgrade
|
User/Host
|
20
|
Storage
|
FTP;
SFTP; Micro SD Card (support max. 256 G); NAS
|
Browser
|
IE
Chrome Firefox
|
Management Software
|
Smart
PSS; DSS; DMSS
|
Mobile
Phone
|
IOS;
Android
|
Certification
|
Certifications
|
CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL:
UL60950-1 CAN/CSA C22.2 No.60950-1-07
|
Port
|
Audio Input
|
1-channel (RCA port)
|
Audio Output |
1-channel (RCA port) |
Alarm Input |
1 channel in: 5mA 3V–5V DC |
Alarm Output |
1 channel out: 300mA 12V DC |
Power
|
Power
Supply
|
12V
DC/PoE (802.3af)
|
Power
Consumption
|
< 5.4W
|
Environment
|
Operating Conditions
|
-40°C
to +60°C (-40°F to +140°F)/less than ≤ 95%
|
Storage Temperature
|
-40°C
to +60°C (-40°F to +140°F)
|
Protection Grade
|
IP67
|
Structure
|
Casing
|
Metal
|
Dimensions
|
166.2
mm × Φ70 mm (6.54" × Φ2.76")
|
Net
Weight
|
0.48
kg (1.1 lb)
|
Gross
Weight
|
0.57
kg (1.3 lb)
|
