| Model | |
| System |
| Main Processor | Embedded processor |
| Operating System | Embedded LINUX |
| Video |
| Input | 16 channel, BNC |
| Standard | Analog | NTSC/PAL |
| HD | 5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps |
| IP | 16+8 up to 6Mp |
| Audio |
| Input | 1 channel, RCA |
| Output | 1 channel, RCA |
| Two-way Talk | Reuse audio input/output channel 1 |
| Display |
| Interface | 1 HDMI, 1 VGA |
| Resolution | 3840×2160, 2560×1440, 1920×1080, 1280×1024, 1280×720 |
| Display Split | 1/4/8/9/16 |
| Privacy Masking | 4 rectangular zones (each camera) |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Resolution | 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF |
| Record Rate | Main Stream: | Main stream:
5MP Mode: 4-ch 5MP@(1-6fps); other channels 5M-N@(1-12fps)
5M-N Mode:
All channel 5M-N@(1–12fps);4M-N,1080p@(1–15fps); 1080N, 720p, 960H, D1,CIF@(1–25/30fps)Sub stream: D1, CIF@(1–15fps) |
Extra
Stream | D1/CIF/QCIF(1~15fps) |
| Bit Rate | 32~6144Kb/s |
| Record Mode | Manual, Schedule(Regular(Continuous), MD), Stop |
| Record Interval | 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
| Trigger Events | Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot,
Buzzer & Screen tips |
| Video Detection | Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
| Playback & Backup |
| Sync Playback | 1/4/9/16 |
| Search Mode | Time/Date, MD & Exact search (accurate to second) |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode | USB Device/Internal SATA burner/Network |
| Network |
| Ethernet | RJ-45 port (10/100M) |
| Network Functions | HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android, Windows Phone |
| Storage |
| Internal HDD | 1 SATA port, up to 10TB |
| Auxiliary Interface |
| USB Interface | 2 ports (1 Rear USB3.0, 1 Front USB2.0) |
| RS485 | 1 port, For PTZ Control |
| General |
| Power Supply | DC12V/2A |
| Power Consumption | 10W(without HDD) |
| Working Environment | -10°C ~+55°C / 10%~90%RH / 86~106kpa |
| Dimension(W×D×H) | Mini 1U, 325mm×255mm×55mm (12.8" x 10" x 2.2") |
| Weight | 0.75KG(without HDD) |
